| Item | Parameter | Remarks |
|---|---|---|
| Vehicle Model | KLF5120GSSE6 | |
| Wheelbase (mm) | 3800 | |
| Engine Model | D25TCIF1 | National VI Emission Standard, Diesel Engine |
| Engine Power (kW) | 110 | |
| Overall Dimensions (L×W×H, mm) | 7050,7070,7100,7550,7570,7600,7130,763023102840,3010 | |
| Curb Weight (kg) | 4520 | |
| Max Gross Vehicle Weight (kg) | 11990 | |
| Working Speed | Engine speed: 1500 r/min | Stationary neutral operation |
| Box Body Effective Volume (m³) | 9.3 | |
| Tank Material | High-quality carbon steel from Wuhan Iron and Steel (4mm thickness) | |
| Front Spraying Width | 15–30 m | |
| Rear Platform Water Cannon | Dust suppression range: 30–35 m, 360° adjustable water cannon | |
| Special Water Pump | High-power water pump, vertical suction lift: 6 m | |
| Standard Configuration | Universal front spray, rear spray, side spray, S-shaped spray, water cannon, fire-fighting interface |
