| Item | Parameter | Remarks |
|---|---|---|
| Vehicle Model | KLF5040ZYSB6 | 4th generation new type compactor |
| Wheelbase (mm) | 2850 | — |
| Tire Specification | 6.50R16LT 10PR steel-belted tire | — |
| Transmission | 5-speed gearbox | — |
| Engine Model | Q23-115C60 (Quanchai, 115 hp) | China VI diesel engine |
| Engine Power (kW) | 85 | — |
| Overall Dimensions (L×W×H, mm) | 5995 × 2090 × 2450 | — |
| Gross Vehicle Weight (kg) | 2850 | — |
| Rated Payload (kg) | 500 | Varies with configuration |
| Curb Weight (kg) | 3865 | Certified based on actual vehicle weight |
| Body Effective Volume (m³) | 5 | — |
| Operation Mode | Electric / Manual / Remote | All three modes are standard equipment |
| Loading Cycle Time | 12–25 s | — |
| Unloading Time | ≤25 s | — |
