| Item | Parameter | Remarks |
|---|---|---|
| Vehicle Model | KLF5162GPSE6 | |
| Wheelbase (mm) | 3950 | |
| Engine Model | YCY30165-60 / D4.0NS6B195 / YCS04200-68 / B6.2NS6B210 / B6.2NS6B230 | National VI Emission Standard, Diesel Engine |
| Engine Power (kW) | 121 / 143 / 147 / 154 / 169 | |
| Overall Dimensions (L×W×H, mm) | 776025003300 | |
| Curb Weight (kg) | 6730 | |
| Max Gross Vehicle Weight (kg) | 16200 | |
| Working Speed | Engine speed 1500r/min | Stationary neutral operation |
| Box Body Effective Volume (m³) | 12 | |
| Tank Material | High-quality carbon steel from Wuhan Iron and Steel (4mm thickness) | |
| Front Spraying Width | 15–30 m | |
| Rear Platform Water Cannon | Dust suppression range: 30–35m, 360° adjustable water cannon | |
| Special Water Pump | High-power water pump, vertical suction lift: 6m | |
| Standard Configuration | Omni-directional front spray, rear spray, side spray, S-shaped spray, water cannon, fire fighting interface |
