| Item | Parameter | Remarks |
|---|---|---|
| Vehicle Model | KLF5180GPSDF6 | |
| Wheelbase (mm) | 3950 | |
| Engine Model | DDi47E210-60 | National VI Emission Standard, Diesel Engine |
| Engine Power (kW) | 154 | |
| Overall Dimensions (L×W×H, mm) | 7475,7675,7450,7650,7910,7935,8410,8435×2500,2550×3300,3350,3400,3240 | |
| Curb Weight (kg) | 6420 | |
| Max Gross Vehicle Weight (kg) | 18000 | |
| Working Speed | Engine speed 1500r/min | Stationary neutral operation |
| Box Body Effective Volume (m³) | 14 | |
| Tank Material | High-quality carbon steel from Wuhan Iron and Steel (4mm thickness) | |
| Front Spraying Width | 15–30 m | |
| Rear Platform Water Cannon | Dust suppression range: 30–35m, 360° adjustable water cannon | |
| Special Water Pump | High-power water pump, vertical suction lift: 6m | |
| Standard Configuration | Omni-directional front spray, rear spray, side spray, S-shaped spray, water cannon, fire fighting interface |
