| Item | Parameter | Remarks |
|---|---|---|
| Vehicle Model | KLF5180GPSHS6 | |
| Wheelbase (mm) | 3950 | |
| Engine Model | YCS04200-68 | National VI Emission Standard, Diesel Engine |
| Engine Power (kW) | 147 | |
| Overall Dimensions (L×W×H, mm) | 7960,7920,7760,7940,7900,7740,7775,8440,8400,8240,82752550,25003230,3400,3350,3300 | |
| Curb Weight (kg) | 10855, 11105 | |
| Max Gross Vehicle Weight (kg) | 18000 | |
| Working Speed | Engine speed 1500r/min | Stationary neutral operation |
| Box Body Effective Volume (m³) | 14.6 | |
| Tank Material | High-quality carbon steel from Wuhan Iron and Steel (4mm thickness) | |
| Front Spraying Width | 15–30 m | |
| Rear Platform Water Cannon | Dust suppression range:30–35m, 360° adjustable water cannon | |
| Special Water Pump | High-power water pump, vertical suction lift: 6m | |
| Standard Configuration | Omni-directional front spray, rear spray, side spray, S-shaped spray, water cannon, fire fighting interface |
