| Item | Parameter | Remarks |
|---|---|---|
| Vehicle Model | KLF5180ZYSE6 | 4th Generation New Compression Type |
| Wheelbase (mm) | 4500 | - |
| Tire Specification | 10.00 Steel Cord Tires | - |
| Transmission | Fast 8-speed Gearbox | - |
| Engine Model | YCS04200-68 (Yuchai 200HP)D4.0NS6B195 (Cummins 195HP)B6.2NS6B230 (Cummins 230HP) | China VI Emission Standard, Diesel Engine |
| Engine Power (kW) | 147/143/169 | - |
| Overall Dimensions【Length × Width × Height (mm)】 | 85902500/25503300/3400 | 4 rear structures available, different structures result in different overall vehicle lengths |
| Maximum Gross Vehicle Weight (kg) | 18000 | - |
| Rated Load Mass (kg) | 8450, 8385, 8070, 8005, 7516, 7581 | - |
| Curb Weight (kg) | 9420, 9800, 10289 | Certified based on actual vehicle weight |
| Effective Compartment Volume (m³) | 14 | - |
| Operation Method | Electric Control / Manual / Remote Control | All 3 operation modes are standard configuration |
| Single Feeding Cycle Time | 12—25S | - |
| Unloading Time | ≤25S | - |
