| Category | Item | Parameters or Configuration |
|---|---|---|
| Overall Vehicle Parameters | Product Model | KLF5040TXSB6 |
| Overall Dimensions【Length × Width × Height (mm)】 | 5150; 520017502250; 2460 | |
| Curb Weight (kg) | 3865; 4080 | |
| Maximum Gross Vehicle Weight (kg) | 4495 | |
| Rated Load Mass (kg) | 285; 500 | |
| Maximum Speed (km/h) | 110 | |
| Rated Passengers | 2 Persons | |
| Chassis Parameters | Engine Model | Q23-95C60China VI Emission Standard, Diesel Engine |
| Category & Manufacturer | BAIC Foton Motor Co., Ltd. | |
| Engine Power (kW) | 70 | |
| Wheelbase (mm) | 2600 | |
| Tires | 6.00R16 Steel Cord Tires | |
| Front Overhang / Rear Overhang (mm) | 1115/1485; 1115/1435 | |
| Braking System | Hydraulic Brake | |
| Number of Leaf Springs | 7/5+3 | |
| Transmission Model | Howo 5-speed | |
| Number of Tires | 6+1 | |
| Chassis Model | BJ1045V9JB3-55 |
