| Item | Parameter | Remarks |
|---|---|---|
| Vehicle Model | KLF5180ZYSE6 | 4th Generation New Compactor Garbage Truck |
| Wheelbase (mm) | 3950 | |
| Tire Specification | 275 Tubeless Tire / 10.00 Steel Wire Tire | |
| Transmission | Fast 8-speed Transmission | |
| Engine Model | YCS04200-68 (Yuchai 200), D4.0NS6B195 (Cummins 195), B6.2NS6B230 (Cummins 230) | National VI Emission Standard, Diesel Engine |
| Engine Power (kW) | 147 / 143 / 169 | |
| Overall Dimensions (L×W×H, mm) | 8040 / 8005 / 7855 / 7755 * 2500 / 2550 * 3300 / 3400 | Four rear structure options; overall vehicle length varies by structure |
| Max Gross Vehicle Weight (kg) | 18000 | |
| Rated Payload (kg) | 8450, 8385, 8070, 8005, 7516, 7581 | |
| Curb Weight (kg) | 9420, 9800, 10289 | Certified based on the actual vehicle weight |
| Box Body Effective Volume (m³) | 12 | |
| Operation Mode | Electric / Manual / Remote | Three operation modes as standard configuration |
| Single Feed Cycle Time | 12–25s | |
| Unloading Time | ≤25s |
