| Item | Parameter | Remarks |
|---|---|---|
| Vehicle Model | KLF5121ZYSE6 | 4th Generation New Type Compactor |
| Wheelbase (mm) | 3800 | |
| Tire Specification | 8.25 Steel-belted tire | |
| Transmission | Wanliyang 6-speed gearbox | |
| Engine Model | D25TCIF1 (Yunnei 150 hp) | China VI emission, diesel engine |
| Engine Power (kW) | 110 | |
| Dimensions (L×W×H in mm) | 7480/7510*2300/2350*2710/3010/3200 | Different rear structures result in different vehicle lengths |
| Max Gross Mass (kg) | 11990 | |
| Rated Mass (kg) | 5240, 5175, 4515, 4580, 4977, 5042 | |
| Curb Mass (kg) | 6620, 7280, 6818 | Certified based on actual vehicle weight |
| Effective Volume of Body (m³) | 10 | |
| Operation Mode | Electric/Manual/Remote | All three operation modes are standard |
| Loading Cycle Time | 12-25 S | |
| Unloading Time | ≤25 S |
