| Item | Parameter | Remarks |
|---|---|---|
| Vehicle Model | KLF5121ZYSE6 | 4th Generation New Compression Type |
| Wheelbase (mm) | 3800 | - |
| Tire Specification | 8.25 Steel Cord Tires | - |
| Transmission | Wanliyang 6-speed Gearbox | - |
| Engine Model | D25TCIF1 (Yunnei 150HP)YCY30165-60 (Yuchai 165HP) | China VI Emission Standard, Diesel Engine |
| Engine Power (kW) | 110/121 | - |
| Overall Dimensions【Length × Width × Height (mm)】 | 7480/75102300/23502710/3010/3200 | 4 rear structures available, different structures result in different overall vehicle lengths |
| Maximum Gross Vehicle Weight (kg) | 11990 | - |
| Rated Load Mass (kg) | 5240, 5175, 4515, 4580, 4977, 5042 | - |
| Curb Weight (kg) | 6620, 7280, 6818 | Certified based on actual vehicle weight |
| Effective Compartment Volume (m³) | 10 | - |
| Operation Method | Electric Control / Manual / Remote Control | All 3 operation modes are standard configuration |
| Single Feeding Cycle Time | 12—25S | - |
| Unloading Time | ≤25S | - |
