| Item | Parameter | Remarks |
|---|---|---|
| Vehicle Model | KLF5141ZYSE6 | 4th Generation New Compression Type |
| Wheelbase (mm) | 3800 | - |
| Tire Specification | 8.25 Steel Cord Tires | - |
| Transmission | Wanliyang 6-speed GearboxFast 8-speed Gearbox | 8.25 Steel Cord Tires are matched with Fast 8-speed Gearbox |
| Engine Model | YCY30165-60 (Yuchai 165HP) | China VI Emission Standard, Diesel Engine |
| Engine Power (kW) | 121kW | - |
| Overall Dimensions【Length × Width × Height (mm)】 | 7750/74502450/2400/23502500 | 4 rear structures available, different structures result in different overall vehicle lengths |
| Maximum Gross Vehicle Weight (kg) | 14060 | - |
| Rated Load Mass (kg) | 5665, 5465, 5265 | - |
| Curb Weight (kg) | 8200, 8400, 8600 | Certified based on actual vehicle weight |
| Effective Compartment Volume (m³) | 11.5 | - |
| Operation Method | Electric Control / Manual / Remote Control | All 3 operation modes are standard configuration |
| Single Feeding Cycle Time | 12—25S | - |
| Unloading Time | ≤25S | - |
